• The motherboard supports larger sizes up to and including ATX specifications

• 12Gb/s direct-connect backplane, compatible with SAS/SATA hard drives

• Support ATX power supply

• Intelligent temperature control, supporting up to 4x8025 fans and 2x6025 fans

Ultra-high computing power

It supports Intel® Xeon® Scalable series processors (lce Lake) and can accommodate 2 high-power CPUs. The motherboard features a native M.2 interface, enabling ultra-high computing power. It has undergone comprehensive upgrades in terms of core, frequency, cache, and interconnect channels. It adopts DDR4 memory technology and supports 2TB memory expansion capability, allowing for on-demand expansion to meet the application needs of ultra-high computing power in digital currency, cloud computing, big data, virtual computing, and other fields

Good heat dissipation control

The unique design of the front-mounted GPU chamber allows the GPU to draw in more cool air, and features a separate GPU cooling duct, forming a ventilation and cooling channel that runs from the front to the back. This design ensures timely removal of the large amount of heat inside the chassis, thereby guaranteeing stable operation of the server

Extraordinary GPU density support

The 4U system can support up to 10 dual-wide, full-height GPU cards for switch interconnection, and is compatible with the NVIDIA GeForce series and NVIDIA Tesla A800. It offers multiple power supply modes, requires no accessory modifications, and provides an unparalleled excellent architecture for pursuing greater computing performance

AI-based intelligent remote management

IPMI remote management enables real-time monitoring and operations, including system startup and shutdown, from a remote location, ensuring timely maintenance by system administrators. It achieves a true redundancy architecture, encompassing fans, power supplies, and storage
